| Model name |
DB-ATC-M30 |
| Image sensor |
1/2.9” Progress CMOS SONY IMX323 Sensor |
| Effective pixels |
P:1920(H)X1080(V);N:1920(H)X1080(V) |
| Unit cell size |
3.0μm (H) x 3.0μm (V) |
| S/N Ratio |
More than 65dB |
| Resolution |
1080P/2MP |
| OSD Language |
ENGLISH / 中文 / SPANISH / FRENCH / 繁体中文 / RUSSIAN / ITALIAN / KOREAN / PORTUGUESE / POLISH |
| Video Output |
AHD/TVI/CVI/ANALOG |
| Shutter Speed |
1/30(1/25) ~ 1/10,000 sec |
| White Balance |
Auto White Balance |
| Backlight Compensation |
YES |
| AGC |
YES |
| Day & Night |
Color/BW/EXT |
| Motion OSD |
OFF / ON |
| Mirror/Flip |
OFF / ON |
| Power Input |
DC12V±10% |
| Power Consumption |
MAX 1W (70mA) without LED |
| Operation Temperature/Humidity |
-20℃ ~ 60℃ |
| Dimension |
38x38x10mm or 32x32x10mm |
| Weight |
5g |
