| Model name |
DB-ATC-H20 |
| Image sensor |
1/2.7”Aptina AR0237 CMOS |
| Effective pixels |
P:1928(H)X1088(V);N:1928(H)X1088(V) |
| S/N Ratio |
More than 41dB |
| Resolution |
1080P/2.1MP |
| OSD Language |
ENGLISH |
| Video Output |
1080p AHD/TVI/CVI/ANALOG |
| Shutter Speed |
1/1 ~ 1/10,000s |
| White Balance |
Auto White Balance |
| Backlight Compensation |
YES |
| AGC |
YES |
| Day & Night |
Day/Night |
| Motion OSD |
OFF / ON |
| Mirror/Flip |
OFF / ON |
| Power Input |
DC12V±10% |
| Power Consumption |
MAX 1W (70mA) without LED |
| Operation Temperature/Humidity |
-20℃ ~ 60℃ |
| Dimension |
38x38x10mm or 32x32x10mm |
| Weight |
5g |
